Objective Magnification

1X 2X

Total Magnification

10X 20X

Zoom ratio

1:2

Working distance(mm)

105

Observation tube inclination

45°

Eyepieces (10X)

Field of view: Φ23mm

Interpupillary distance adjustment range

52mm-75mm(10X)

Diopter adjustment

Provided on left eyepiece tube only

Magnification adjustment

Magnification with both hand wheels in horizontal direction Rotating

Focusing for BC & TC models only

Rack-and-pinion drive on ball bearing guides, focusing range: 51mm
